WLP Wireless Load Cell &Position
The Bright Integrated Wireless
Load Cell/Accelerometer is the comprehensive field solution that accurately measures and monitors both load and position in a
single wireless unit. Featuring a compact, all-in-one design for improved
convenience, reliability and accessibility, this integrated unit is fully solar
powered and easily maintained.
The receiving module’s standard
output for load and range offers a convenient replacement option for
conventional systems. Data is transmitted via a 2.4GHz digital channel for
real-time system updates. In addition to reduced installation time, long-term
service and maintenance costs are significantly reduced over the life of the
system.
Features
· Completely solar
powered with battery backup
· Standard output (load):
4-20mA or 0-10mV
· Standard output
(range): 4-20mA or 1.3-7V
· Transmits data via
2.4GHz digital channel
Benefits
· Integrated measuring
and monitoring system
· Compact, space-saving
design
· Greatly reduces cable
failure risk
Download:WLP Wireless Load Cell &Position_Brochure
